Whelen M7 Linear Super-LED Lighthead

The Whelen M7 Linear Super-LED Lighthead is a mid-sized member of the M Series family of lightheads. The M Series is the only Patented Linear-LED lightheads with a bold look to the future in fire, ambulance and rescue truck emergency lighting. Designed to stand-up to the harsh environments and standards of the industry while providing top of the line performance!

Features:

• Surface mounted via two screws.
• Super-LEDs provide unmatched high intensity warning, low current consumption.
• Unique lens shape is completely illuminated with patented Linear-LED designed reflector assembly.
• Lens and reflector are a sealed assembly.
• Available with color (same as LEDs) or clear lens.
• Mounting screws are located outside of the sealed lens/reflector assembly eliminating water infiltration.
• Replaceable light engine is accessed from the rear of the lens/reflector assembly.
• Rear gasket ensures that the lighthead and optional flange does not touch the vehicle's surface.
• Updated design allows for faster and easier installation.
• M7 lightheads have 164 Scan-Lock flash patterns.
• Choose from Solid, Left/Right, Top/Bottom, In/Out, or Diagonal sequencing.
• Meets KKK 1822F, NFPA 1901, SAE and EC65 specifications.
• 82 flash patterns meet California Title XIII compliant.
• Hi/Low intensity function included (Violet wire).
• Hard coating on lens resists scratches, chemical and corrosive damage.
• Current Draw @ 12.8 VDC: 2.25 (Peak*), 0.9 (Average). * in steady on mode
• Dimensions (approximate): 3-3/8" (86mm) H x 7-5/8" (194mm) W x 1-3/8" (35mm) D.

Whelen 5 Year Warranty
